How to install a wall mounted hair dryer

　　The wall mounted hair dryer is derived from the classic European design, luxurious and beautiful, with noble quality, safe and reliable. It can be used for hair drying after washing, with a gentle wind force that does not harm hair quality. The safety protection cover makes the body and mind more comfortable, and the skin more comfortable. Wall mounted hair dryers are made of high temperature resistant, high-strength PC plastic with good insulation and moisture-proof properties. There are also iron shell hair dryers that can be sprayed through soldering and have strong corrosion resistance. How to install a wall mounted hair dryer:

　　1、 Open line installation

　　1. Drill 2- ¥ 6 installation holes in the installation position according to the size of the screws, and plug them in with the provided rubber plugs. Tighten the installation screws to the holes on the hook.

　　2. Align the installation bayonet at the back of the wall mounted hair dryer shell with the hook and insert it. Use the screws provided with the machine to fix the front and rear shells together on the wall, and then plug the screw glue into the screw hole position.

　　3. Plug in the power supply and turn the main power switch to the "ON" position.

　　2、 Dark wire installation

　　1. Drill 2- ¥ 6 installation holes in the installation position according to the size, and insert them with the provided rubber plugs. Tighten the installation screws to the holes on top of the hooks.

　　2. First loosen the screws that are fastened to the front housing, then move the front housing away and remove the power cord with the original plug from the wiring terminal.

　　3. Open the plastic of the wall mounted hair dryer inlet hole, pass the reserved power supply through the inlet hole, and then align the installation tab at the back of the back shell with the hook to insert it. Use the screws provided with the machine to fix the back shell to the wall.

　　4. Reserve the power cord and connect it to the original power cord terminal (pay attention to the direction of the N and L wires when wiring). After connecting, place the terminal in its original position.

　　5. After checking that there are no errors, install the front shell on the rear shell and secure it with screws. Plug in the power supply and pull the main power switch to the "ON" position.
